The EDRA Pressure switch from Condor USA.
Pressure Connection
| Permissible operating voltage range | = ± 10 % |
| Operating voltage influence (at ± 10% operating voltage fluctuation) | = < 0,1 % |
| Duty factor(ED) | = 100% |
| Permissible ambient and media temperature | = -20°C bis +80°C |
| Permissible ambient humidity (rel. humidity, non-condensing) | = 10 % bis 90 % |
| Permissible storage temperature | = -40°C bis +80°C |
| Clearance and creepage distances | = VDE 0110 |
| Working position | = any position |
| Power consumption | = max. 1 VA |
| Material | = ABS flameproof, UL-approved |
| Mounting | = snap on 35 mm DIN-rail connector acc. to EN 50 035 |
| Enclosure-protection | = IP 40 |
| Protection against shock | = VBG 4 |
| Terminals | = Cage clamps |
| Cross section | = 2,5 mm2 |
| Weight | = 255 g |
| Series voltage (acc. to VDE 0660 and VDE 0110 Group C) | = 250 V-AC |
| Maximum continuous current (per contact) | = 6 A-AC |
| Maximum switching capacity (per contact) | = 1.500 VA (AC) 50 W (DC) |
| Mechanical life (cycles) | = approx. 1 x 107 |
| Electrical life (max. load) [cycles] | = approx. 2 x 105 |
