| Rated operational current Ie AC 1 [Ue=240 V (1~)] | = 10 A |
| Rated operational current Ie AC 15 [Ue=240 V (1~)] | = 4 A |
| Rated operational current Ie DC 13 [Ue=240 V (1~)] | = 0.1 A |
| Permissible motor rating (1~ 230 V) | = 0.55 kW |
| Motor switching capacity (UL 508, CSA 22.2) [Ue=125 VAC] | = 0.5 HP |
| Motor switching capacity (UL 508, CSA 22.2) [Ue=250 VAC] | = 0.5 HP |
| Rated operational current Ie [(UL 508, CSA 22.2) Ue=250 VAC] | = 15 A |
| Rated operational current Ie [(UL 508, CSA 22.2) Ue=12 VDC] | = 6 A |
| Vibration resistance (10 bis 1000 Hz) | = 4g |
| Degree of protection acc. to DIN 40 050/IEC 529 (with rubber grommets) | = IP 54 |
| Degree of protection acc. to DIN 40 050/IEC 529 (with cable glands M20) | = IP 65 |
| Ambient temperature range | = -20 °C .. +70 °C |
| Cross-sections [Cage clamp (without cable end sleeve)] | = 1.5 mm² |
| Cross-sections (Screw clamp) | = 2.5 mm² |
